Technical specifications技術(shù)規(guī)格：

Input輸入:

AC Socket交流輸入接口: C6  梅花尾

Input range交流輸入接口：90Vac~264Vac

Frequency頻率：47Hz~63Hz

Input current輸入電流：1.5A Max at 100Vac input voltage

Efficiency效率：84% Min. at nominal input voltage, maximum load and measured at the end of DC cable

Output輸出

Output Power輸出功率：90W

Output Volts/Amps輸出電壓/電流：19.5V/4.62A

Output ripple and noise輸出紋波：350 mV peak to peak

DC Plug輸出接口: do it follow up customer request   按照客戶項目需求提供

Dimensions 尺寸(mm)

L127.0 x W51.0 x H30.5
