Technical specifications技術(shù)規(guī)格：

Input輸入:

AC Socket交流輸入接口: C6, C8 8字尾   梅花尾

Input range輸入電壓范圍：90Vac~264Vac

Frequency頻率：47Hz~63Hz

Input current輸入電流：1.5A Max at 100Vac input voltage

Efficiency效率：84% Min. at nominal input voltage, maximum load and measured at the end of DC cable

Output輸出

Output Power輸出功率：65W

Output Volts/Amps輸出電壓/電流：19.50V/3.34A

Output ripple and noise輸出紋波：350 mV peak to peak

DC Plug輸出接口:  do it follow up customer request 按照客戶項目需求提供

Dimensions (mm)尺寸

L108.0 x W46.0 x H29.5
